Kisok / POS Mini PCs

We use these systems (POS = Point of Sale = Point of Sale) every day, paying in shops, restaurants, cafes. We are so used to this that we do not pay attention to the operation of this device, the main component of which seems to be a box with money.

In fact, everything is not so simple. The simplest operation of paying for goods at the checkout is a whole sequence of complex actions.

First, it is reading the barcode of the product with a scanner. Secondly, the POS system must get the cost of the goods from the database using the barcode. This is followed by the receipt of money by the cashier and the printing of a fiscal check. At the same time, the system writes off the sold unit of goods from the list of those in the trading floor so that when the quantity of goods falls below a certain level, the staff will receive a signal about the need for additional display.

Polywell Computers mini PCs for POS and information kiosks are distinguished by their high reliability due to the use of industrial grade components and make them highly popular with system integrators and companies operating industrial facilities and networks.

_____________________________________________________________________________________________________

Model Processor Chipset Memory Graphics Network M.2 MSata USB2.0 USB3.0 Ports Expansion OtherIO Audio
N3150A1 N3150 Braswell-u 2 DDR3SO 8th Gen. HD 1 Realtek 1 3 R+3 H 1 R 1 HDMI+1 VGA+1 LVDS/H 2 MiniPCIe GPIO+LPT 7.1 ALC892
Nano-Z83 x5-Z8350 Cherry Trail 0 DDR3OB 8th Gen. HD 1 Realtek 1 3 F 1 F 1 HDMI+1 VGA 2 MiniPCIe 5.1 Intel
J1900AL2 J1900 Bay Trail 1 DDR3SO 7th Gen. HD 2 Realtek 1 1 R+1 F+2 H 1 R 1 HDMI+1 VGA+1 LVDS/H MiniPCIe-F TPM+GPIO+1xPS/2/H 5.1 ALC662
J1900AE J1900 Bay Trail 1 DDR3SO 7th Gen. HD 1 Realtek 1 4 R + 3H 1 R 1 HDMI+1 VGAH+1 LVDS/H MiniPCIe-F+PCIe 1x GPIO 5.1 ALC662
H110L2 6/7th Socket 1151 H110 2 DDR4 Intel HD 530 Intel HD 630 1 Realtek\RTL8111H 2-8 1 2 R+4 H 4 R 2 DP+1 HDMI MiniPCIe+PCIe 16x 5.1 ALC662
H110L2C12 6/7th Socket 1151 H110 2 DDR4 Intel HD 530 Intel HD 630 2 Realtek 2-8 1 2 R+2 H 4 R 1 DP+1 HDMI+1 VGA 2 MiniPCIe+PCIe 16x 1xPS/2 5.1 ALC662
N2600-300R N2600 NM10 2 DDR3SO Intel HD 3600 1 Realtek\RTL8111E 1 3 R+1 F+2 H 1 HDMI+1 VGA 2 MiniPCIe+PCIe 1x 1xPS/2 5.1 ALC662
B150V3 6/7th Socket 1151 B150 2 DDR4 Intel HD 530 Intel HD 630 1 Realtek\RTL8111H 2-8 1 2 R+4 H 4 R 2 DP+1 HDMI MiniPCIe+PCIe 16x 5.1 ALC662
Nano-N3450G N3450 Apollo Lake 0 DDR3OB Intel HD 500 1 Realtek+11ac WiFi/BT 1 2 R 2 F 1 HDMI+1 DP 5.1 ALC662
J1900AEL2 J1900 Bay Trail 1 DDR3SO 7th Gen. HD 2 Realtek\RTL8111F 1 2 R+2 H 1 R 2 HDMI+1 VGAH+1 LVDS/H MiniPCIe-F+PCIe 1x GPIO 5.1 ALC662 7.1 ALC892
N4200AEL2 N4200 Apollo Lake 2 DDR3SO Intel HD 505 2 Intel\i211AT 1 5 R 4 R 1 HDMI+2 DP+1 LVDS MiniPCIe+PCIe 1x GPIO+TPM 5.1 ALC662
H110L2V 6/7th Socket 1151 H110 2 DDR4 Intel HD 530 Intel HD 630 2 Realtek\RTL8111H 2-8 1 2 R+4 H 4 R 2 DP+1 VGA+1 HDMI/H MiniPCIe+PCIe 16x 5.1 ALC662
H310A1 8/9th Socket 1151 H310 1 DDR4SO Intel UHD 630 1 Intel\i219V 1 2 4 H 4 R+2 H 1 HDMI+1 VGA/H+1 LVDS/H 5.1 ALC662
Nano-6100D i3-6100u Skylake-u 1 DDR4SO Intel HD 520 1 Realtek 1 1 2 F 4 F 1 HDMI+1 VGA 2 MiniPCIe 5.1 ALC662
Nano-8000FL2C i7-8550u Skylake-uKaby Lake-u/-r 1 DDR4SO Intel UHD 620 Intel HD 610 1 Realtek+option:1 Realtek 1 1 option 2 R+2 H 2 F + 2 R 1 HDMI+1 VGA\DP GPIO 5.1 HDMI
Nano-N3350C N3350 Apollo Lake 0 DDR3OB Intel HD 500 1 Realtek+ WiFi 1 1 1 R 4 F 1 HDMI+1 VGA(Option) SD(Option) 2.1 ALC269
Nano-J1900L2V3 J1900 Bay Trail 1 DDR3SO 7th Gen. HD 2 Realtek 1 2 F+2 H 2 F 1 HDMI+1 VGA MiniPCIe-F 5.1 ALC662
Nano-N4100D N4000 Gemini Lake 1 DDR4BS Intel UHD 605 1 Realtek\RTL8111H 1 2 F+2 R 2 F 1 HDMI2.0+1 DP PB/F 5.1 ALC662
Nano-J1900L2C2 J1900 Bay Trail 1 DDR3SO 7th Gen. HD 2 Realtek 1 3 F+2 H 1 F 1 HDMI+1 VGA 2 MiniPCIe 5.1 ALC662
i2311 6/7/8/9th Socket 1151 H310C 1 DDR4SO Nvidia GT1030 1 Realtek\RTL8111H 1 2 H 4 R 1 HDMI+1 LVDS/H 5.1 ALC662
HM170L2/AEL2 i5-6300HQ HM170 2 DDR4SO Intel HD 530 1 RJ45+option:1 RJ45 1 3 R 2 H+2 H/R 2 R+4 H 1 DP+1 HDMI+1 VGA+1 LVDS/H 1x MiniPCIe+1x PCIe 3.0x16 1xPS/2/H+TPM+GPIO 5.1 ALC662
H410A1 10th Socket 1200 H410 2 DDR4SO Intel UHD 630 1 Reltek\RTL8111F 1 2 4R 2R+2F 1 DP + HDMI LPT/S 5.1 ALC662
Nano-8000C2 i5-8250u Kaby Lake-r Kaby Lake-u 0 DDR4OB Intel UHD 620 Intel HD 620 1 Realtek 1 2 R 2 R+2 F 1 HDMI 5.1 HDMI
J1900AC6 J1900 Bay Trail 1 DDR3SO 7th Gen. HD 1 Realtek 1 3 R+1 F+2 H 1 R 1 HDMI+1 VGA+1 LVDS/H MiniPCIe-F TPM+1xPS/2/H 5.1 ALC662
Q370L3E2 8/9th Socket 1151 vPro Q370 2 DDR4SO Intel UHD 630 1 Intel\i219V+2 Intel\i210AT 1-4/8 4 2 R+4 H 4 R+1 H 2 DP+1 DVI+1 LVDS/H 1 PCIe 16x+1 PCIe 4x GPIO+LPT 7.1 ALC888
Q470L2G 11th/10th Socket 1200 Q470 2 DDR4SO Intel UHD 1 Intel\i219V+1 Intel\i211 2-8 2 4 H 4 R+2 F 1 DP+1 HDMI+1 HDMI2.0+1 eDP\LVDS/H+VGA header (co-lay with eDP) 1 MiniPCIe+1 PCIe 16x GPIO+TPM 5.1 ALC662
Nano-U10L2 i7-10710U Comet Lake-u 2 DDR4SO Intel UHD 4K 2 x Intel® i211+i219 1 2F + 2S 2F + 2S 1 HDMI+ 1 DP+ 1 Type-C+ 3 USB+ 1 COM+ 2 LAN+ 1 SIM+ 1 SD+ S/PDIF GPIO 5.1 ALC662
Nano-U8L2 i5-8259u Coffee Lake-u Comet Lake-u 2 DDR4SO Intel UHD 4K 2 x Intel® i211+i219 1 2F + 2S 2F + 2S 1 HDMI+ 1 DP GPIO 5.1 ALC662
H410AL2 10th Socket 1200 H410 2 DDR4SO Intel UHD 630 2 Realtek\RT8111H 1 2R 2R+2F 1 HDMI+1DP/VGA Option: LPT/S 5.1 ALC662
H410A 10th Gen Socket 1200 H410 2 DDR4SO Intel UHD 630 Realtek\RTL8111F + WiFi 1 4R 2R + 2F HDMI + DP/VGA 5.1 ALC662
Nano-U8FL2C6 i7-8565U Whiskey Lake-u 2 DDR4SO Intel UHD 620/610 2 x Intel® i211A+i219LM 1 1 4H 4(USB3.1)R 1 HDMI+1DP+1LVDS/eDP optional; x8 GPIO, TPM, SPI 5.1 ALC662
Nano-J1900D J1900 Bay Trail 7th Gen. HD 1 Realtek 1 3F+2R 1F 1 HDMI+1 VGA MiniPCIe-F+MiniPCIe-H TF 5.1 ALC662
Nano-H510A/Q570A 11th/10th Socket 1200 H510/Q570 2 DDR4 Intel UHD 750 1 Intel\I219LM 2-8 3F 1F 1 HDMI2.0/F+1 DP/F M.2-2280+M.2-2230 TPM 5.1 ALC662
Slim-H510B/Q570B i9-11900T Intel H510 2 DDR4SO Intel UHD 750 2 Intel I219LM + 1 M.2 2230 + WiFi/BT 1 2 R + 3 F 2 R + 1 F 2 HDMI + 1 DC + 2 Lan ALC662
i63C / i65C 10th/8th Gen. u-Series Comet Lake-u/Whiskey Lake-u SOC 2 DDR4SO 10th/8th Gen. UHD Graphics Intel® i219+Realtek® RTL8111H w/ SIM 1 4 R+2F 1 HDMI 2.0+1 HDMI 1.4+1 DP 1.2 MiniPCIe 5.1 ALC662
Nano-N3350DL2 N3350 Apollo Lake DDR3L Intel HD 500 Realtek RTL8111F 1 2 2 1HDMI + 1 DP + 1 COM HD Sound via HDMI
H510MXM 11th/10th Socket-S H510 2 DDR4SO MXM + UHD 750/630 2 LAN + WiFi/BT 1 M.2 2280 4 F 2 R HDMI 2.0 + DP 1.2 ALC662 (5.1)
AIO-JA215C Celeron J4125 Gemini Lake (SOC) 4GB DDR4SO UHD 600 LAN + Dual-Band WiFi/BT 4 + 1 H 2 HDMI+VGA+2 eDP+LVDS 4x4 GPIO H
AIO-JA215D Celeron J1900 Bay Trail (SOC) DDR3LSO Intel HD Graphics LAN+SIM 5 1 HDMI+VGA+LVDS LPT ALC662 (5.1)
H610V3 Alder Lake H610 2 DDR4SO UHD 770/730 Realtek® RTL8125B 3 R 2 R 2 HDMI, DP Realtek® ALC897
H610L2 Alder Lake H610 2 DDR4 U-DIMM UHD 770/730 2 LAN M.2-2280/2242 3 R 2 R 2 HDMI, DP ALC897
Nano-N6400G
H12A Intel® Core™ i5-12450H Alder Lake 2 DDR4SO Intel UHD 1 LAN + WiFi/BT 1 M.2 2280 4 R HDMI + VGA 1 M.2 2230 Realtek® ALC897
i12P 12th Gen Core-P Series Alder Lake-P (SOC) 2 DDR4 SODIMM Iris Plus 2 LAN+WiFi/BT+5G/4G NVMe/SSD 2 HDMI 2.0 + DP 1.4 2 COM 7.1 ALC897
H610AL2 12th Gen Socket-S series H610 2 DDR4 SODIMM UHD 2 LAN+WiFi/BT+5G/4G NVMe/SSD/2.5"SATA SSD/HD 2 R 2 F 2 HDMI, DP 2 COM 7.1 ALC897
H110L4C6 Intel® Core™ Intel® H110/C236 Chipset 2 DDR4SO UHD 4 LAN 2 SATA, mSATA, PCIe x4 NVMe 4 F 4 R HDMI + VGA + DVI-D + LVDS/eDP 6-10 COM HD
Slim-HM370AL2 Intel 9th Gen. Core H-Series Intel QM370/HM370 South Bridge 2 DDR4SO UHD 630 2 LAN M.2-2280 2 F 2 F + 2 R HDMI ALC662 (5.1)
NUC-N7000D
NUC-U11C
i13U-4HDMI
Nano-U12FL2C6
