 ARM-based Product

X55-LX2

Dual LAN+WiFi/BT, 2 M.2 NVMe/SSD+5G/4G-LTE+Sim slot, 3 USB+TF Slot
Featured Highlights
ARM® Cortex®-A55 Processor
RK3568 SoC
Mali™-G52-2EE GPU, HDMI 2.0
2GB/4GB/8GB Onboard DDR4 Memory
16GB/32GB/64GB eMMC, M.2 NVMe SSD, TF slot
2 Gigabit LAN, M.2 5G/4G-LTE+sim Slot
2 USB 2.0, 1 USB 3.0 OTG
HD Audio Sound (2x3.5mm Jacks)
Power Supply: DC12V 2A Power Adapter (UL/CE/FCC Certified)
OS Support: Android 12, Linux.
Applications: Set Top Box, Network Security, Digital Signage, Kiosk, POS, IPTV, Entertainment, Audi Player, Digital Home, IoT, etc.


SKU: X55-LX2
Product specifications
Processor

• ARM® Cortex®-A55 4Core up to 1.80GHz

Chipset

• Rockchip RK3568 (SOC)

Graphics

• ARM® Mali™-G52 EE 4Core Graphics Processor
• 1 x HDMI® 2.0, 4K 60Hz Graphics port
• 1 x LVDS/eDP header (for SBC / Panel PC / All-in-One)

Memory

• 2GB/4GB/8GB DDR4 (built-in, non-changeable)

Network

• 2 x Gigabit (10/100/1000 Mb/s) LAN (optional 1 LAN with extra USB port in Plastic chassis, refer to model X55
• WIFI-5 802.11 a/b/g/n/ac (Optional WIFI-6 802.11 a/b/g/n/ac/ax )
• Bluetooth 4.2 (Optional BT 5.4)
• 1 x M.2 3042/3052 (for 5G/4G-LTE Module pairing with SIM Slot)
• Optional Internal GPS with external Antenna connector
• Wake on LAN, PXE boot (Diskless) supported

Expansion Slot

• 1 x M.2 3042/3052 (for 5G/4G-LTE Module pairing with SIM Slot) or GPS Module
• 1 x M.2 2280 (for PCIe NVMe SSD)

Storage

• 16GB/32GB/64GB eMMC 5.1
• 1 x M.2 2280 (for PCIe NVMe SSD)
• 1 x TF (microSD 3.0) slot, supports 1TB

Audio

•  2 x 3.5mm Audio Out/Mic In jacks
• Optional Optical S/PDIF Digital Audio port (refer to model X55 Plastic SKU)

Back Panel I/O

• 1 x USB 2.0 port
• 2 x LAN ports (Optional single LAN with extra USB port, refer to Model X55)
• 1 x HDMI® 2.0 port
• 1 x DC12V-In 2.5mm Power Connector
• 1 x Firmware Control Hidden Switch

Internal I/O

• 2 x USB 2.0 headers
• 1 x Battery Connector for Real Time Clock

Other I/O

• 1 x USB 2.0 ports (Side)
• 1 x USB 3.0 OTG port (Side)
• 1 x TF/microSD slot (Side)
• 2 x Audio/Mic jacks (Side)
• 1 x IR Receiver (Front)
• 1 x WiFi+BT Antenna (Side)
• 1 x Optional 4G/5G Cellular Antenna (Side)
• 1 x Optional On/Off Power Switch (Side)

Function

• 1 x GPIO header (8 I/O)
• 4 x UART headers (for Serial / Console)
• Optional GPS
• Optional NFC

System BIOS

• AMI® UEFI BIOS
• 32KB EEPROM
• Watchdog supported

Chassis

Nano-LX series Aluminum Fanless Enclosure (Option: Plastic chassis with single LAN)
• Dimensions: 5.11"(W) x 5.00"(D) x 1.02"(H), Weight: 1.5 lb. (Net) 5 lb. (gross with packaging)
• Color: Black or Silver as default color, custom colors available with special order
• Supports VESA, wall mount or rackmount brackets

Power Supply

• Power: DC12V 2A Power Adapter 2.5mm plug (UL/CE/FCC Certified)
• Power Cord: Standard US Power Cord included, European Power Cord available as option
• Powered by PoE supported
• Energy Star Compliance, Idle mode at <1W

OS Support

• Android 12, Linux.

Application

• Set Top Box, Network Security, Digital Signage, Kiosk, POS, IPTV, IoT, Digital Home, Entertainment, Audio Player, etc.

Environment

• Operating Temperature: 0 to +40 C
• Non operating temperature: -20 to +70 C
• Vibration - Operating: 9.8 m/s2(1.0G) 5 to 500Hz
• Vibration - Non operating: 49 m/s2(5.0G) 15 to 500Hz
• Shock - Operating: 3,920 m/s2 (400G) 2ms
• Shock - Non-Operating: 8,820 m/s2 (900G) 1ms
• Operating Relative Humidity: 8% to 90% (non-condensing)
• Non-operating Relative Humidity: 5% to 95% (non-condensing)
• MTBF: 100,000 Hours
• FCC, CE, RoHS Certified
• TAA Compliance SKU available

*
*
*
