Storage Server

SUMA 4036A / 4036S

36 x SATA/SAS, HW RAID-5/6 Acceleration 4 x GigaLAN, High Performance 12Gbps iSCSI/NAS/SAN
Featured Highlights
•  Data file sharing among Windows, Linux OS, and Macintosh users, with user name, password protection,
  and managed access in local workgroups.
The backup and recovery application provides system backup, remote boot and recovery for Windows clients.
Can act as a Dynamic Host Configuration Protocol (DHCP) server.
Can also act as a DHCP client.
Can be used as linear storage or set up as RAID 0.
User-friendly Web interface for setting up users and access rights.
Built-in FTP server provides convenient high-speed file transfers.
Supports Redundant Power Supply.

SUMA 4036A is an intelligent network storage solution for the small office or medium office, and will cost less than comparable Windows file servers.



SKU: SUMA 4036A / 4036S

Product specifications
Processor
• Intel Xeon™ Processor E5-2600 V4 Series
Memory
• ECC 32GB Registered Memory
• Optional: up to 1TB system memory
OS and Storage Manager
• Linux OS and NAS/iSCSI WEB based Manager
• Optional: Solaris, Windows Server, MS Storage Server, VMware, FreeBSD, Other Open Soruce Linux.
File System

• XFS, EXT3 standard
• Optional: ZFS, NTFS, or any file system supported by the x86 platform

Network I/O

• 4 Gigabit LAN ports
• Option: Additional 4xGigabit LAN, 10Gbit Ethernet, Fibre Channel for SAN

Network Service

• DHCP client/server (default is DHCP client/Static)
• Network Protocol: CIFS/SMB, NFS, FTP
• iSCSI (optional)

Management Interface

• Web GUI
• E-mail notification
• Local Host Access via VGA and Keyboard

Expansion Slot

• Up to 6 x PCIe 3.0 slots

Remote Boot Function

• Requires NIC with PXE support on client

File Sharing

• Authorizes users to access shared folder using passwords (by default, there is one "Public" shared folder)

Access Control

• Allows users to access shared files for "Read Only" or "Read/Write"

I/O Ports

• 2 x USB 3.0 connectors
• 2 x USB 2.0 connectors
• 2 x USB 3.0 and 4 x USB 2.0 headers
• VGA graphics

Client Support

• MS Windows® 8, 7, XP and Windows Server, Linux , FreeBSD, Solaris and Mac
• Snap Shot Backup and Recovery Client Support
• Active Directory, Rsync are supported

Remote Controls

• Power on/off, system reset + USB
• IPMI, KVM over IP, Remote Power On/Off is supported

Indicators

• Power, LAN and HDD LEDs

Cooling

• Hot-Swap cooling fans

Power Supply

• 1280W 1+1 redundant 80 Plus Platinum power supply UR/FCC/CE Certified

Operating Temperature

• From 10ºC to 35ºC (50ºF to 95ºF)

Non-Operating Temperature

• From -40ºC to 70ºC (-40ºF to 158ºF)

Operating Humidity

• From 10% to 90% relative humidity

EMI Safety

• CE/FCC

Dimensions

• 4U Rackmount
• Height 7" (178mm)
• Width 17.2" (437mm)
• Depth 27.5" (699mm)
• Gross Weight 80 lbs (36.3 kg)

Warranty

• SAS and SATA-E Hard Driver carry 5 year,SATA-N carries 3 year
• Base system:3 year standard parts and depot labor;lifetime toll free phone support.
• Optional:3 or 5-year(total years) extended warranty with advanced parts replacement service.
• Optional:7+year extended warranty service available.
• On-site service is available with additional cost.

ServerFilter
Storage/RAID

• 36 x 3.5" SATA/SATA-II Hot-Swap Drive
• RAID 5, 6, 10, 1 and 0 with Hot Spare
• Hardware- accelerated RAID 6 Capable for maximum reliability

*
*
*
